Knife and fork mould Details
This paper takes the plastic spoon as the object and introduces its injection mold design process in detail. In the design, UG and AUTOCAD software are mainly used, and the three-dimensional modeling of the parts is carried out according to the parts drawing of the parts, and the model is analyzed. The plastic part is the shell, and the multi-cavity side gate is adopted in the design process of the pouring system. Design and carry out the necessary calculations and structural design of the molded parts. The design of the Longji Dashui standard mold base has been improved. Finally, the production of engineering drawings was completed by Autocad, and various factors were considered in the design.
